Example Aircraft

This book uses a twin-engine, propeller driven airplane as an illustrative example to demonstrate various aircraft design concepts. This section summarizes preliminary specifications for this notional aircraft.

NOTE: The requirements listed here are not exhaustive. Additional requirements may be introduced in later sections.

Requirements:

Requirement	Specification
Crew	1 pilot (200 lbs)
Payload	5 passengers (200 lbs each, including baggage)
Takeoff and Landing	\(\leq\) 1500 ft groundrun (sealevel, standard conditions)
Powerplant	Twin piston engines with propellers
Pressurization	None
Certification	14 CFR Part 23, Level 2, Low speed
Range	1200 nautical miles
Cruise altitude	8,000 ft
Cruise speed	\(\geq\) 200 KTAS

Mission Profile:

Below image depicts the mission profile created using some of the above requirements. Note that it also includes a reserve mission (red lines) to account for additional fuel according to CFR Part 91.151 and Part 91.167.

NOTE: These requirements and the associated mission profile are intended solely for instructional purposes and should not be interpreted as a Request for Proposal (RFP).
